How to use Azure OpenAI with Open WebUI

Using Azure OpenAI with Open WebUI

This post will cover how to use Azure OpenAI with Open WebUI and LiteLLM (without Ollama) in order to connect to an OpenAI model hosted in Azure AI Studio (or Foundry as it is now known).

Open WebUI Docker Compose

version: '3.8'

services:
  openwebui:
    image: ghcr.io/open-webui/open-webui:main
    container_name: lc-open-webui
    restart: unless-stopped
    ports:
      - "8090:8080"
    env_file: stack.env
    volumes:
      - open-webui:/app/backend/data
    networks:
      - lc_network
  litellm-proxy:
    image: ghcr.io/berriai/litellm:main-latest
    container_name: lc-litellm-proxy
    restart: unless-stopped
    ports:
      - "4000:4000"
    env_file: stack.env
    depends_on:
      - litellmproxy_db
    environment:
      DATABASE_URL: postgresql://${POSTGRES_USER}:${POSTGRES_PASSWORD}@litellmproxy_db:5432/${POSTGRES_USER}
    command: ["--config", "/app/config.yaml", "--detailed_debug"]
    volumes:
      - /opt/litellmproxy/litellm_config.yaml:/app/config.yaml
    networks:
      - lc_network
  litellmproxy_db:
    image: postgres:17.2-alpine3.21
    container_name: lc-postgresql
    restart: unless-stopped
    env_file: stack.env
    shm_size: 96mb
    volumes:
      - postgresdatalitellmproxy:/var/lib/postgresql/data
    networks:
      - lc_network

volumes:
  postgresdatalitellmproxy:
  open-webui:
  ollama:

networks:
  lc_network:
    driver: bridge

You will also need the following environment variables as we are running Portainer:

AZURE_API_BASE=https://xxx-aiservices.openai.azure.com
AZURE_API_KEY=<API KEY. SEE 3 BELOW>
AZURE_API_VERSION=<FROM URL. 2 SEE BELOW>
AZURE_MODEL=<SEE 1 BELOW>
POSTGRES_PASSWORD=<PASSWORD OF YOUR CHOOSING>
POSTGRES_USER=litellm
LITELLM_MASTER_KEY=<ANY RANDOM VALUE STARTING WITH sk->
LITELLM_SALT_KEY=never_change_this_key_123
WEBUI_SECRET_KEY=<PASSWORD OF YOUR CHOOSING>

AZURE_API_BASE

Your Azure OpenAI deploymentURL

AZURE_MODEL

LiteLLM requires the AZURE_MODEL variable to be in the format “azure/DEPLOYMENT_NAME” when using Azure OpenAI deployments. So in our case this value will be “azure/gpt-4o” as can be seen at number 1 in the image.

AZURE_API_KEY

This is just the API key as in the image below at number 3.

AZURE_API_VERSION

If you look at 2 in the image below, you will see the URL contains an API version. Use that API version.

LITELLM_MASTER_KEY

Must start with “sk-” and is the key you will use when logging in as admin and for the REST APIs.

LiteLLM Config

In the docker compose file you will see this line: /opt/litellmproxy/litellm_config.yaml:/app/config.yaml

This means that LiteLLM is looking for the litellm_config.yaml file on the host on which you have docker installed. This is what that file must look like:

model_list:
  - model_name: gpt-4o
    litellm_params:
      model: os.environ/AZURE_MODEL
      api_base: os.environ/AZURE_API_BASE
      api_key: os.environ/AZURE_API_KEY
      api_version: os.environ/AZURE_API_VERSION

This file is used to define all your models.

In your case, the only model we have is gpt-4o, which is our Azure OpenAI model, and we define all the parameters for that model. The parameters pretty much just read the environment variables we defined as part of the docker-compose file.

Endpoints

Several endpoints will be accessible after deploying this compose file (replace the IP and port with your host):

LiteLLM

Swagger Docs	http://192.168.1.109:4000
User Interface	http://192.168.1.109:4000/ui (log in with the LITELLM_MASTER_KEY)
Model Cost Map (not local but important)	https://models.litellm.ai/

Model Pricing

In LiteLLM under models you will see the gpt-4o model with pricing. This is the default pricing and is a bit off from the actual pricing.

Here is the Azure pricing for our model: https://azure.microsoft.com/en-us/pricing/details/cognitive-services/openai-service/

The below corresponds with the “Model Version” in the Azure AI Studio screenshot above.

OpenWeb-UI

OpenWeb-UI User Interface

http://192.168.1.109:8090/

Link Open WebUI with LiteLLM

We need to tell OpenWeb-UI how to use the gpt-4o model we have defined in LiteLLM:

Click on Admin Panel

Click on Settings, Connections, then the plus Icon to add a new connection

The URL will be the litellm service name as defined in the docker compose file. In our case it is “litellm-proxy” and the internal port is 4000.

The Key is the “sk-” value you defined in the “LITELLM_MASTER_KEY” environment variable. Include the entire key, including “sk-“

Then click the refresh button, and you will see the green message up top.

Open a new chat, and you will see the “gpt-4o” model listed in the dropdown. That little icon tells us it is an external model.
